Q: How do LED stadium lights work?

LED stadium lights ( How to do sports lighting design? ) are high powered fixtures designed to illuminate stadiums and venues. They are usually mounted very high, between forty and one hundred feet in height. This height can go even higher if the stadium lighting requirements are high. Because of their high mounting heights and large illumination area, they usually have a narrow beam angle, which can range from 15 degrees to 60 degrees. They also sometimes use asymmetric light distribution to ensure reasonable illumination (reduce glare and light pollution).

Question 1

How much light is required for a cricket pitches?

Accepted Answer

According to the EN12193 lighting standard, for an average training and recreational cricket stadium, the illumination requirement is between 300 and 500 lux, which is sufficient for moderate recreation, training, or mini-matches between players. If converted to lumen (taking into account maintenance factors etc.), it is estimated that a cricket pitch with a diameter of 130 metres would require more than 6,000,000 lumens. For a professional match pitch, 500-750 lux is required, which is suitable for high intensity matches. If converted to lumen, this would require more than 10,000,000 lumens.

Question 2

How many watts of lights are in a cricket pitches?

Accepted Answer

Let's take the EN12193 standard as an example. The wattage required for different lighting classes is definitely different, for example as follows

Class I: 750lux, estimated 15,000,000 lumens, based on 150lm/w luminous efficacy, estimated 100,000W.

Class II: 500lux, estimated need 10,000,000 lumens, based on 150lm/w efficiency, estimated need 70,000W.

Class III: 300lux, estimated 6,000,000 lumens, estimated 40,000W at 150lm/w.

For ICC lighting standards, more than 2,000,000W is usually required.

Question 3

How do LED stadium lights work?

Accepted Answer

LED stadium lights ( How to do sports lighting design? ) are high powered fixtures designed to illuminate stadiums and venues. They are usually mounted very high, between forty and one hundred feet in height. This height can go even higher if the stadium lighting requirements are high. Because of their high mounting heights and large illumination area, they usually have a narrow beam angle, which can range from 15 degrees to 60 degrees. They also sometimes use asymmetric light distribution to ensure reasonable illumination (reduce glare and light pollution).
